The Foil Drive Assist MAX is our flagship model, delivering maximum power, runtime, thrust, and versatility for all foiling enthusiasts. Suitable for beginners and experienced riders, the Assist MAX enhances your adventures in all disciplines of foiling. Discover the ultimate foiling experience with the Assist MAX !
It doesn't matter if you're surfing, downwind foiling, winging, or in flat water, the Assist MAX is for everyone! The MAX system offers longer runtime and is recommended for those wanting a diverse foiling experience.
-
Learn to Foil
-
Flatwater Foiling
-
Surf, Downwind, Wing, or Pump with longer runtime
-
Adaptable into all disciplines
-
Also recommended for heavier riders
Tech Specs
Maximum Thrust: 27.5kg (60.6lbs) with Three Blade Alloy Props
Total Install Weight: 4.8-5.8kg (10.5-12.7lbs) depending on battery
Max. Dimensions: L525 x W125 x H50mm
Min. Dimensions: L415 x W125 x H50mm
Operating Voltage: 40V
Runtime (Generalised): 40min-4hrs depending on use case, battery, and other variables
Recharge Time: Approx. 2-3.5hrs (Power Battery)
Batteries: IP68 rated, dust and water resistant
Install on any Foil Board & Mast
Gen2 Foil Drive Systems mount between your mast plate and the board. As foil mast tracks are universal, this means it fits any board! Simply use the provided locking T nuts and longer mast bolts. Sandwich your Gen2 Foil Drive between your gear for optimal weight distribution and a clean top board surface.
Removable Motors
With three simple screws, the motor plug can be removed, allowing the rider to change their motor height through swapping between different cable lengths.
With options to use your own foil mast or a fully integrated option, there are more ways to tune your setup than ever!
MAX Power Battery
The largest MAX battery, offering the longest run time with high power performance. This battery must be used with the Assist MAX, Nose Cone A.
Volts: 40V
Energy: 498.69Wh
Battery Weight: 2.6kg (5.7lbs)
Weight (Installed): 4.5kg (9.9lbs)
Dimensions (Installed): L525 x W125 x H50mm
Dimensions (Battery Only): L420 x W75 x H40mm
Maximum boost: 24%
Max boost time: 18 seconds
MAX Sport Battery
The smaller, lighter MAX battery, with reduced weight and runtime. This battery must be used with the Assist MAX, Nose Cone B.
Volts: 40V
Energy: 332.64Wh
Battery Weight: 1.8kg (3.9lbs)
Weight (Installed): 3.4kg (7.4lbs)
Dimensions (Installed): L415 x W125 x H50mm
Dimensions (Battery Only): L290 x W75 x H40mm
Maximum boost: 20%
Max boost time: 15 seconds
